PCB Laser Marking System LM510C-EU

Part No.: VT-LM510C-EU

Category: Lasermarking

CO2 laser marking machine LM510-C-EU - Precise, fast and flexible marking for printed circuit boards

The fully automatic LM510-C-EU CO2 laser marking machine from VennTek enables reliable and permanent marking of 1D and 2D codes, QR codes, texts, symbols and graphics directly on printed circuit boards (PCBs). Thanks to state-of-the-art laser technology, high marking speed and flexible software integration, it is the ideal solution for traceability and quality control in electronics production. Benefit from low-maintenance technology, simple operation and maximum process reliability - for efficient production processes and perfect marking results.

Description & Technical data

CO2 Laser Marking Machine LM510-C-EU
The Innovative Solution for PCB Marking

The LM510-C CO2 Laser Marking Machine has been specifically developed to meet the requirements of modern electronics manufacturing. It enables precise, fast, and durable marking of printed circuit boards (PCBs) – a crucial step for traceability, quality assurance, and automation in production.

Technical Highlights and Benefits

Fully Automatic Operation: The LM510-C integrates seamlessly into existing production lines and operates fully automatically, reducing the need for personnel and increasing process reliability.
Versatile Marking Capabilities: Mark 1D barcodes, 2D codes, QR codes, text, symbols, and graphics directly on the surface of your PCBs – flexible and adaptable to your production needs.
High-Precision Laser Technology: The CO2 laser source ensures sharp markings without mechanical stress on the material, maintaining the integrity of your PCBs at all times.
High Marking Speed: Thanks to the modern laser system and optimized software, the LM510-C achieves impressive marking speeds, minimizing cycle times and boosting productivity.
Low Maintenance and Durable: The robust construction and high-quality laser unit ensure reliable, low-maintenance operation – ideal for continuous industrial use.
Intuitive Operation: The user-friendly software interface enables easy setup, programming, and monitoring of the marking process – even for changing product series.
Flexible Integration: The LM510-C can be easily integrated into existing MES and ERP systems, ensuring seamless traceability of your products.

Application and Benefits

The LM510-C is ideal for companies that require the highest standards of traceability and quality for their PCBs. The permanent laser marking is tamper-proof, abrasion-resistant, and meets all relevant industry standards. By automating the marking process, you save time, reduce error sources, and ensure the long-term quality of your products.

Why Choose the LM510-C?

With the CO2 Laser Marking Machine LM510-C, you are opting for a future-proof solution for your electronics manufacturing. You will benefit from maximum flexibility, high precision, and a technology that makes your production processes more efficient and secure. Enhance your competitiveness with automated, high-quality, and cost-effective marking solutions.

Technical Specifications

Laser Source	CO² Laser (optional Fiber)
Output Power	10 W
Wavelength	1064 nm
Marking Area	110 x 110 mm
Minimum Line Width	0.01 mm
Minimum Character Size	0.2 mm
Repeatability	±0.003 mm
Max Speed	7000 mm/s
Cooling	Air Cooling
Power Supply	AC 230 V, 50/60 Hz
Operating Conditions	0–35 °C, Humidity ≤ 90%

Benefits of the LM510-C Laser Marking Machine

High Marking Quality: Clear and durable markings for reliable traceability.
Increased Production Efficiency: Automated processes reduce error rates and increase production speed.
Versatility: Suitable for various PCB materials and sizes.
User-Friendliness: Easy operation through intuitive software and user-friendly interfaces.
Integration: Compatible with existing production systems and easily integrated into manufacturing processes.

Application Areas

The LM510-C Laser Marking Machine is ideal for marking PCBs in various industries, including:

Electronics Manufacturing
Prototyping
Quality Assurance and Traceability
Flexible PCB Manufacturing
